PUROSIL SILICONE PRODUCTS

EPDM 45 DEGREE ELBOWS

Provides standard connections for air intake systems that require

articulation or vibration isolation.s.

Features & Benefits

  1. •Specifically formulated EPDM compound.

  2. •Available in nitrile and chloroprene and silicone compounds.

  3. •Vacuum collapse rating exceeds 4" Hg. mercury.

  4. •Recommended for temperatures: -60°F to +300°F duty.

  5. •Complies with physical properties requirements of ASTM D2000 3BA715A14B13C12F17.

    1. Bullet70 ±5 Shore A Hardness

    2. Bullet1500 PSI Tensile, minimum.

    3. Bullet250% Elongation, minimum.

    4. BulletAir Age, 70 Hrs. at 100° C.

    5. BulletDurometer Change, +10, maximum.

    6. BulletTensile Change, -25%, maximum.

    7. BulletElongation Change, -25%, maximum.

    8. BulletComp. Set, Method B, at 70° C. 25% maximum.

    9. BulletOzone Resistance, D1171, Method B, Quality Retention Rating: 100%

    10. BulletLow Temp. Brittleness, D2137, Method A. Non Brittle After 3 Minutes at -40° C.
